MMBD701LT3G
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - RF
Description
Tape & Reel (TR) Schottky - Single Single 3 RF Diode 1pF @ 20V 1MHz 100mA 200mW 70V
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.139008
≥1 USD $0.139008
≥10 USD $0.13114
≥100 USD $0.123716
≥500 USD $0.116714
≥1000 USD $0.110107
Inventory: 1554
Minimum: 1
-
+
Technical Details
Physical
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature -55°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8541.10.00.60
Subcategory Other Diodes
Voltage - Rated DC 70V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 100mA
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MMBD701
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Polarity Standard
Power Dissipation-Max 200mW
Element Configuration Single
Diode Type Schottky - Single
Output Current 100mA
Capacitance @ Vr, F 1pF @ 20V 1MHz
Frequency Band ULTRA HIGH FREQUENCY
Diode Capacitance-Max 1pF
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
