MBD301G
RoHS
/
Package TO-226-2, TO-92-2 (TO-226AC)
Category Discrete Semiconductor Products / Diodes - RF
Description
Bulk Schottky - Single Single 2 RF Diode 1.5pF @ 15V 1MHz 10A 280mW 30V
PDF
/
Inventory: 2154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.19mm
Length 5.21mm
Height 5.33mm
Technical
Frequency Band ULTRA HIGH FREQUENCY
Capacitance @ Vr, F 1.5pF @ 15V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 30V
Peak Reverse Current 200nA
Forward Voltage 600mV
Breakdown Voltage 30V
Max Reverse Leakage Current 200nA
Forward Current 10mA
Output Current 100mA
Power Dissipation 280mW
Diode Type Schottky - Single
Element Configuration Single
Polarity Standard
Number of Elements 1
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 10A
Peak Reflow Temperature (Cel) 260
Terminal Form THROUGH-HOLE
Terminal Position BOTTOM
Voltage - Rated DC 30V
Subcategory Other Diodes
Capacitance 1.5pF
HTS Code 8541.10.00.60
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Published 2001
Packaging Bulk
Operating Temperature -55°C~125°C TJ
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Surface Mount NO
Package / Case TO-226-2, TO-92-2 (TO-226AC)
