MA4P1450-1091T
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD
Category Discrete Semiconductor Products / Diodes - RF
Description
RF DIODE PIN 100V 10W
PDF
/
Buying Options
Total Price: USD $10.99
Unit Price: USD $10.9912
≥1 USD $10.9912
≥10 USD $10.10504
≥100 USD $9.686336
≥500 USD $9.218
Inventory: 1151
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Forward Resistance-Max 0.75Ohm
Diode Res Test Frequency 100MHz
Diode Res Test Current 50mA
Minority Carrier Lifetime-Nom 0.008 μs
Resistance @ If, F 750mOhm @ 50mA 100MHz
Diode Capacitance-Nom 1.8pF
Frequency Band HIGH FREQUENCY TO ULTRA HIGH FREQUENCY
Breakdown Voltage-Min 100V
Voltage - Peak Reverse (Max) 100V
Reverse Voltage 50V
Capacitance @ Vr, F 2.5pF @ 50V 1MHz
Forward Voltage 1V
Case Connection ISOLATED
Power Dissipation 4W
Diode Type PIN - Single
Element Configuration Single
Power Dissipation-Max 10W
Number of Elements 1
Pin Count 2
Terminal Form WRAP AROUND
Terminal Position END
Technology POSITIVE-INTRINSIC-NEGATIVE
Subcategory PIN Diodes
HTS Code 8541.10.00.80
Additional Feature LOW DISTORTION
Type Switch
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case 2-SMD
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
