MA4L011-134
RoHS
RoHS compliant
RoHS compliantPackage Die
Category Discrete Semiconductor Products / Diodes - RF
Description
RF DIODE PIN 35V CHIP
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.280936
≥1 USD $4.280936
≥10 USD $4.061376
≥100 USD $3.644256
≥500 USD $3.07347
≥1000 USD $2.919796
Inventory: 825
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Package / Case Die
Number of Pins 134
Diode Element Material SILICON
Technical
Operating Temperature -55°C~125°C TJ
Packaging Bulk
Published 2013
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Additional Feature LOW LEAKAGE
HTS Code 8541.10.00.40
Subcategory PIN Diodes
Technology POSITIVE-INTRINSIC-NEGATIVE
Terminal Position UPPER
Pin Count 2
JESD-30 Code S-XUUC-N1
Number of Elements 1
Max Current Rating 100mA
Element Configuration Single
Diode Type PIN - Single
Forward Current 10mA
Application LIMITER
Peak Reverse Current 10μA
Capacitance @ Vr, F 0.18pF @ 0V 1MHz
Reverse Voltage 35V
Reverse Voltage (DC) 35V
Frequency Band HIGH FREQUENCY TO KU B
Diode Capacitance-Nom 0.2pF
Resistance @ If, F 2.1Ohm @ 10mA 500MHz
Diode Capacitance-Max 0.18pF
Minority Carrier Lifetime-Nom 0.01 μs
Diode Res Test Frequency 500MHz
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
