BAR6306WE6327HTSA1
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - RF
Description
RF DIODE PIN 50V 250MW SOT323-3
PDF
/
Inventory: 7428
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case SC-70, SOT-323
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2011
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
HTS Code 8541.10.00.80
Technology POSITIVE-INTRINSIC-NEGATIVE
Terminal Position DUAL
Terminal Form GULL WING
Reach Compliance Code compliant
Base Part Number BAR63-06
JESD-30 Code R-PDSO-G3
Number of Elements 2
Configuration COMMON ANODE, 2 ELEMENTS
Power Dissipation-Max 250mW
Diode Type PIN - 1 Pair Common Anode
Application SWITCHING
Current - Max 100mA
Capacitance @ Vr, F 0.3pF @ 5V 1MHz
Voltage - Peak Reverse (Max) 50V
Breakdown Voltage-Min 50V
Frequency Band S B
Resistance @ If, F 1Ohm @ 10mA 100MHz
Diode Capacitance-Max 0.3pF
Minority Carrier Lifetime-Nom 0.075 μs
Diode Forward Resistance-Max 2Ohm
