HSMS-286P-TR2G
RoHS
/
Package 6-TSSOP, SC-88, SOT-363
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE SCHOTTKY DETECT HF SOT-363
PDF
/
Inventory: 1389
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Number of Pins 6
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.80
Subcategory Other Diodes
Voltage - Rated DC 4V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 100mA
Number of Elements 4
Configuration 2 BANKS, SERIES CONNECTED, CENTRE TAP, 2 ELEMENTS
Diode Type Schottky - 2 Pair Series Connection
Forward Current 1A
Forward Voltage 350mV
Capacitance @ Vr, F 0.25pF @ 0V 1MHz
Reverse Voltage (DC) 4V
Frequency Band C B
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
