HSMS-282F-TR1G
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE SCHOTTKY RF 15V 1A SOT-323
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.1995
Inventory: 11805
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Package / Case SC-70, SOT-323
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 12Ohm
Terminal Finish Tin (Sn)
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 15V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Number of Elements 2
Max Current Rating 1A
Element Configuration Common Cathode
Diode Type Schottky - 1 Pair Common Cathode
Output Current 1A
Max Reverse Leakage Current 100nA
Forward Voltage 500mV
Max Repetitive Reverse Voltage (Vrrm) 15V
Capacitance @ Vr, F 1pF @ 0V 1MHz
Frequency Band C B
Resistance @ If, F 12Ohm @ 5mA 1MHz
Diode Capacitance-Max 1pF
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
