HSMS-282E-BLKG
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - RF
Description
BROADCOM LIMITED HSMS-282E-BLKG RF Schottky Diode, Barrier, Dual Common Anode, 15 V, 10 mA, 500 mV, 1 pF, SOT-323
PDF
/
Inventory: 2831
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Package / Case SC-70, SOT-323
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Published 2007
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.80
Capacitance 1pF
Subcategory Rectifier Diodes
Voltage - Rated DC 15V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Number of Elements 2
Max Current Rating 1A
Element Configuration Common Anode
Diode Type Schottky - 1 Pair Common Anode
Output Current 1A
Forward Current 10mA
Max Reverse Leakage Current 100nA
Breakdown Voltage 15V
Forward Voltage 500mV
Max Reverse Voltage (DC) 1V
Max Repetitive Reverse Voltage (Vrrm) 15V
Capacitance @ Vr, F 1pF @ 0V 1MHz
Reverse Voltage (DC) 15V
Frequency Band C B
Resistance @ If, F 12Ohm @ 5mA 1MHz
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
