HSMS-2820-TR1G
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - RF
Description
AVAGO TECHNOLOGIES HSMS-2820-TR1G RF Schottky Diode, Barrier, Single, 15 V, 1 A, 340 mV, 1 pF, SOT-23
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
≥3000 USD $2.14795
Inventory: 63685
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 12Ohm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 15V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Base Part Number HSMS-2820
Number of Elements 1
Max Current Rating 1A
Power Dissipation-Max 0.25W
Element Configuration Single
Diode Type Schottky - Single
Output Current 1A
Forward Current 1A
Max Reverse Leakage Current 100nA
Breakdown Voltage 15V
Forward Voltage 340mV
Max Repetitive Reverse Voltage (Vrrm) 15V
Capacitance @ Vr, F 1pF @ 0V 1MHz
Reverse Voltage (DC) 15V
Frequency Band C B
Resistance @ If, F 12Ohm @ 5mA 1MHz
Diode Capacitance-Max 1pF
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
