HSMS-2804-TR2G
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE SCHOTTKY RF CC 70V SOT-23
PDF
/
Inventory: 7553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Diode Capacitance-Max 2pF
Resistance @ If, F 35Ohm @ 5mA 1MHz
Capacitance @ Vr, F 2pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 70V
Forward Voltage 1V
Max Surge Current 1A
Max Reverse Leakage Current 200nA
Output Current 1A
Diode Type Schottky - 1 Pair Common Cathode
Element Configuration Common Cathode
Max Current Rating 1A
Number of Elements 2
Base Part Number HSMS-2804
Current Rating 1A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 70V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
