HSMP-481B-TR1
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE PIN ATTENUATOR 100V SOT323
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 12307
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Diode Forward Resistance-Max 3Ohm
Diode Res Test Frequency 100MHz
Diode Res Test Current 100mA
Resistance @ If, F 3Ohm @ 100mA 100MHz
Diode Capacitance-Nom 0.35pF
Reverse Test Voltage 50V
Breakdown Voltage-Min 100V
Voltage - Peak Reverse (Max) 100V
Capacitance @ Vr, F 0.4pF @ 50V 1MHz
Current - Max 1A
Diode Type PIN - Single
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G3
Base Part Number HSMP-481B
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology POSITIVE-INTRINSIC-NEGATIVE
Subcategory PIN Diodes
HTS Code 8541.10.00.60
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SC-70, SOT-323
