HSMP-3860-BLKG
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE PIN GP 50V 1A SOT-23
PDF
/
Buying Options
Total Price: USD $5.34
Unit Price: USD $5.3371
≥1 USD $5.3371
≥10 USD $4.3795
≥100 USD $4.2427
≥500 USD $4.1059
≥1000 USD $3.9691
Inventory: 3103
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Diode Res Test Frequency 100MHz
Diode Res Test Current 1mA
Minority Carrier Lifetime-Nom 0.5 μs
Resistance @ If, F 1.5Ohm @ 100mA 100MHz
Diode Capacitance-Nom 0.2pF
Recovery Time 80 ns
Reverse Voltage 50V
Capacitance @ Vr, F 0.2pF @ 50V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 50V
Breakdown Voltage 50V
Application ATTENUATOR; SWITCHING
Forward Current 1A
Output Current 1A
Diode Type PIN - Single
Element Configuration Single
Power Dissipation-Max 0.25W
Max Current Rating 1A
Number of Elements 1
Base Part Number HSMP-3860
Current Rating 1A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology POSITIVE-INTRINSIC-NEGATIVE
Voltage - Rated DC 50V
Subcategory PIN Diodes
HTS Code 8541.10.00.80
Additional Feature LOW DISTORTION
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Resistance 3Ohm
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Published 2006
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
