HSMP-3823-BLKG
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - RF
Description
AVAGO TECHNOLOGIES HSMP-3823-BLKG RF / Pin Diode, Common Anode, 0.6 ohm, 50 V, SOT-23, 3, 0.8 pF
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 16503
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Strip
Published 2008
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature LOW DISTORTION
HTS Code 8541.10.00.80
Subcategory PIN Diodes
Technology POSITIVE-INTRINSIC-NEGATIVE
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G3
Qualification Status Not Qualified
Number of Elements 2
Configuration COMMON ANODE, 2 ELEMENTS
Power Dissipation-Max 0.25W
Diode Type PIN - 1 Pair Common Anode
Application SWITCHING
Current - Max 1A
Capacitance @ Vr, F 0.8pF @ 20V 1MHz
Voltage - Peak Reverse (Max) 50V
Breakdown Voltage-Min 50V
Reverse Test Voltage 20V
Diode Capacitance-Nom 0.6pF
Resistance @ If, F 600mOhm @ 10mA 100MHz
Diode Capacitance-Max 0.8pF
Minority Carrier Lifetime-Nom 0.07 μs
Diode Res Test Current 10mA
Diode Res Test Frequency 100MHz
Diode Forward Resistance-Max 0.6Ohm
Compliance
RoHS Status RoHS Compliant
