HMPP-3890-TR1
RoHS
/
Package 0505 (1412 Metric)
Category Discrete Semiconductor Products / Diodes - RF
Description
Diode PIN Switch 100V 4-Pin Mini-PAK T/R
PDF
/
Inventory: 5453
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Diode Res Test Frequency 100MHz
Diode Res Test Current 1mA
Minority Carrier Lifetime-Nom 0.2 μs
Diode Capacitance-Max 0.3pF
Resistance @ If, F 2.5Ohm @ 5mA 100MHz
Diode Capacitance-Nom 0.2pF
Frequency Band ULTRA HIGH FREQUENCY
Reverse Voltage 5V
Capacitance @ Vr, F 0.3pF @ 5V 1MHz
Forward Current 1A
Output Current 1A
Diode Type PIN - Single
Element Configuration Single
Max Current Rating 1A
Number of Elements 1
Time@Peak Reflow Temperature-Max (s) 20
Current Rating 1A
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Technology POSITIVE-INTRINSIC-NEGATIVE
Voltage - Rated DC 100V
Subcategory PIN Diodes
Terminal Finish Tin (Sn)
Resistance 2.5Ohm
Type Switch
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case 0505 (1412 Metric)
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
