HMPP-3865-BLK
RoHS
/
Package 0505 (1412 Metric)
Category Discrete Semiconductor Products / Diodes - RF
Description
Diode PIN Attenuator/Switch 50V 4-Pin Mini-PAK Bulk
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 431
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Package / Case 0505 (1412 Metric)
Number of Pins 4
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Published 2008
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
Capacitance 200FF
Subcategory PIN Diodes
Voltage - Rated DC 50V
Technology POSITIVE-INTRINSIC-NEGATIVE
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) 20
Case Code (Metric) 1412
Case Code (Imperial) 0505
Number of Elements 2
Configuration SEPARATE, 2 ELEMENTS
Max Current Rating 1A
Diode Type PIN - 2 Independent
Output Current 1A
Forward Current 1A
Application ATTENUATOR; SWITCHING
Breakdown Voltage 50V
Capacitance @ Vr, F 0.2pF @ 50V 1MHz
Reverse Voltage 50V
Recovery Time 80 ns
Frequency Band ULTRA HIGH FREQUENCY
Diode Capacitance-Nom 0.2pF
Resistance @ If, F 22Ohm @ 1mA 100MHz
Minority Carrier Lifetime-Nom 0.5 μs
Diode Res Test Current 1mA
Diode Res Test Frequency 100MHz
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
