WNSC101200WQ
RoHS
RoHS compliant
RoHS compliantPackage TO-247-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
SILICON CARBIDE POWER DIODE
PDF
/
Buying Options
Total Price: USD $5.92
Unit Price: USD $5.919379
≥1 USD $5.919379
≥10 USD $5.229984
≥100 USD $4.810068
Inventory: 18
Minimum: 1
-
+
Technical Details
Technical
Diode Type Silicon Carbide Schottky
Current - Reverse Leakage @ Vr 110μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 1.6V @ 10A
Case Connection CATHODE
Operating Temperature - Junction 175°C Max
Output Current-Max 10A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 10A
Number of Phases 1
Reverse Recovery Time 0ns
Rep Pk Reverse Voltage-Max 1200V
Capacitance @ Vr, F 510pF @ 1V 1MHz
Non-rep Pk Forward Current-Max 110A
Reverse Current-Max 200μA
Reverse Test Voltage 1200V
Speed No Recovery Time > 500mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
JESD-30 Code R-PSFM-T2
Reference Standard IEC-60134
Terminal Position SINGLE
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Compliance
RoHS Status RoHS Compliant
Physical
Surface Mount NO
Package / Case TO-247-2
Mounting Type Through Hole
Supply Chain
Factory Lead Time 16 Weeks
