Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description STANDARD POWER DIODE
PDF
/
Buying Options
Total Price: USD $3.05
Unit Price: USD $3.0536
≥1 USD $3.0536
≥10 USD $2.42264
≥100 USD $2.07658
≥500 USD $1.845862
≥1000 USD $1.580515
≥3000 USD $1.488221
Inventory: 630
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Reverse Test Voltage 1600V
Reverse Current-Max 50μA
Forward Voltage-Max 1.12V
Non-rep Pk Forward Current-Max 1045A
JEDEC-95 Code TO-247
Rep Pk Reverse Voltage-Max 1600V
Number of Phases 1
Application GENERAL PURPOSE
Output Current-Max 60A
Case Connection CATHODE
Diode Type RECTIFIER DIODE
Configuration SINGLE
Number of Elements 1
Operating Temperature (Min) -55°C
Operating Temperature (Max) 150°C
JESD-30 Code R-PSFM-T2
Reference Standard IEC-60134
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Additional Feature LOW LEAKAGE CURRENT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active

Physical

Diode Element Material SILICON
Surface Mount NO

Supply Chain

Factory Lead Time 8 Weeks
