BYC8D-600,127
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 8A TO220AC
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.666864
≥100 USD $0.483912
≥500 USD $0.40436
≥1000 USD $0.344142
≥3000 USD $0.306504
Inventory: 1514
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-2
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin (Sn)
Terminal Position SINGLE
Reach Compliance Code not_compliant
Base Part Number BYC8-600
Reference Standard IEC-60134
JESD-30 Code R-PSFM-T2
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 40μA @ 600V
Voltage - Forward (Vf) (Max) @ If 2.9V @ 8A
Case Connection CATHODE
Forward Current 8A
Operating Temperature - Junction 150°C Max
Application HYPER FAST RECOVERY POWER
Voltage - DC Reverse (Vr) (Max) 600V
Number of Phases 1
Reverse Recovery Time 20ns
Rep Pk Reverse Voltage-Max 600V
JEDEC-95 Code TO-220AC
Reverse Current-Max 40μA
Compliance
RoHS Status RoHS Compliant
