VS-20ATS12PBF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode 1.2KV 20A 3-Pin(3+Tab) TO-220AB Tube
PDF
/
Inventory: 5013
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Peak Non-Repetitive Surge Current 300A
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Reverse Current 100μA
Average Rectified Current 20A
Max Reverse Voltage (DC) 1.2kV
Forward Voltage 1.1V
Voltage - DC Reverse (Vr) (Max) 1200V
Operating Temperature - Junction -40°C~150°C
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 20A
Current - Reverse Leakage @ Vr 100μA @ 1200V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Common Anode
Pin Count 3
Reach Compliance Code unknown
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Published 2015
Packaging Tube
Physical
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
