VS-10ETF10PBF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 10A TO220AC
PDF
/
Buying Options
Total Price: USD $12.37
Unit Price: USD $12.3747
≥1 USD $12.3747
≥10 USD $10.1536
≥100 USD $9.8363
≥500 USD $9.519
≥1000 USD $9.2017
Inventory: 8409
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.65mm
Length 10.51mm
Height 15.25mm
Technical
Natural Thermal Resistance 0.5 °C/W
Recovery Time 310 ns
Max Forward Surge Current (Ifsm) 160A
Reverse Voltage 1kV
Peak Non-Repetitive Surge Current 185A
Max Repetitive Reverse Voltage (Vrrm) 1kV
Peak Reverse Current 100μA
Reverse Recovery Time 310 ns
Average Rectified Current 10A
Forward Voltage 1.33V
Voltage - DC Reverse (Vr) (Max) 1000V
Max Surge Current 185A
Operating Temperature - Junction -40°C~150°C
Forward Current 10A
Voltage - Forward (Vf) (Max) @ If 1.33V @ 10A
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Base Part Number 10ETF10
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Published 2011
Packaging Tube
Physical
Number of Pins 2
Package / Case TO-220-2
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 8 Weeks
