SS3P4LHM3_A/I
RoHS
RoHS compliant
RoHS compliantPackage TO-277, 3-PowerDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 40V 3A TO277A
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.48224
≥100 USD $0.335104
≥500 USD $0.261624
≥1000 USD $0.212643
≥3000 USD $0.190098
Inventory: 6343
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 250μA
Non-rep Pk Forward Current-Max 150A
JEDEC-95 Code TO-277A
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 40V
Voltage - DC Reverse (Vr) (Max) 40V
Application EFFICIENCY
Output Current-Max 3A
Operating Temperature - Junction -55°C~150°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 470mV @ 3A
Current - Reverse Leakage @ Vr 250μA @ 40V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
JESD-30 Code R-PDSO-F3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position DUAL
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101
Published 2016
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case TO-277, 3-PowerDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
