SS12P3L-M3/86A
RoHS
RoHS compliant
RoHS compliantPackage TO-277, 3-PowerDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Schottky 30V 12A 3-Pin(2+Tab) SMPC T/R
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.46376
≥100 USD $0.360536
≥500 USD $0.305624
Inventory: 1165
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.15mm
Length 4.35mm
Height 1.2mm
Technical
Max Forward Surge Current (Ifsm) 280A
Peak Non-Repetitive Surge Current 280A
Capacitance @ Vr, F 930pF @ 4V 1MHz
JEDEC-95 Code TO-277A
Max Repetitive Reverse Voltage (Vrrm) 30V
Peak Reverse Current 1mA
Number of Phases 1
Average Rectified Current 12A
Max Reverse Voltage (DC) 30V
Forward Voltage 560mV
Application EFFICIENCY
Max Surge Current 280A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 1mA
Forward Current 12A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 560mV @ 12A
Current - Reverse Leakage @ Vr 1mA @ 30V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Anode
Number of Elements 1
Pin Count 3
Base Part Number SS12P3
Terminal Form FLAT
Terminal Position DUAL
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series eSMP?
Published 2014
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-277, 3-PowerDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
