SD101BWS-G3-08
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Schottky Diodes & Rectifiers 30mA 50Volt 2A IFSM
PDF
/
Inventory: 9862
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-76, SOD-323
Weight 4.309128mg
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2017
Series Automotive, AEC-Q101
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
HTS Code 8541.10.00.70
Subcategory Rectifier Diodes
Max Power Dissipation 150mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
JESD-30 Code R-PDSO-G2
Number of Elements 1
Element Configuration Single
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 200nA @ 40V
Voltage - Forward (Vf) (Max) @ If 1V @ 15mA
Forward Current 30mA
Operating Temperature - Junction -55°C~125°C
Output Current-Max 0.03A
Current - Average Rectified (Io) 30mA DC
Forward Voltage 950mV
Max Reverse Voltage (DC) 50V
Average Rectified Current 30mA
Reverse Recovery Time 1 ns
Peak Reverse Current 200nA
Max Repetitive Reverse Voltage (Vrrm) 50V
Capacitance @ Vr, F 2pF @ 0V 1MHz
Max Forward Surge Current (Ifsm) 2A
Compliance
RoHS Status ROHS3 Compliant
