S1BA-E3/5AT
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 100V 1A DO214AC
PDF
/
Inventory: 989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Recovery Time 1 μs
Reverse Voltage 100V
Peak Non-Repetitive Surge Current 30A
Capacitance @ Vr, F 8pF @ 4V 1MHz
Peak Reverse Current 3μA
Reverse Recovery Time 1 μs
Average Rectified Current 1A
Max Reverse Voltage (DC) 100V
Forward Voltage 1.1V
Current - Average Rectified (Io) 1A
Voltage - DC Reverse (Vr) (Max) 100V
Max Surge Current 30A
Operating Temperature - Junction -55°C~150°C
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Current - Reverse Leakage @ Vr 3μA @ 100V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Single
Base Part Number S1B
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2011
Packaging Tape & Reel (TR)
Physical
Supplier Device Package DO-214AC (SMA)
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
