RGP10KHE3/53
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Automotive AEC-Q101Superectifier? Tape & Box (TB) Through Hole Standard Diode Standard 15pF @ 4V 1MHz 1A 150ns 800V
PDF
/
Inventory: 7905
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AL, DO-41, Axial
Number of Pins 2
Supplier Device Package DO-204AL (DO-41)
Technical
Packaging Tape & Box (TB)
Published 2016
Series Automotive, AEC-Q101, Superectifier?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 800V
Voltage - Forward (Vf) (Max) @ If 1.3V @ 1A
Max Reverse Leakage Current 5μA
Operating Temperature - Junction -65°C~175°C
Max Surge Current 30A
Voltage - DC Reverse (Vr) (Max) 800V
Current - Average Rectified (Io) 1A
Max Reverse Voltage (DC) 800V
Average Rectified Current 1A
Reverse Recovery Time 150 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 800V
Capacitance @ Vr, F 15pF @ 4V 1MHz
Peak Non-Repetitive Surge Current 30A
Recovery Time 500 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
