MURS340HE3/9AT
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Tape & Reel (TR) Surface Mount Standard Single Diode Standard 1.25V @ 3A 3A 75ns 1.25V
PDF
/
Inventory: 9407
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Supplier Device Package DO-214AB (SMC)
Technical
Packaging Tape & Reel (TR)
Published 2012
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Base Part Number MURS340
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 400V
Voltage - Forward (Vf) (Max) @ If 1.25V @ 3A
Forward Current 4A
Operating Temperature - Junction -65°C~175°C
Max Surge Current 125A
Voltage - DC Reverse (Vr) (Max) 400V
Current - Average Rectified (Io) 3A
Forward Voltage 1.25V
Max Reverse Voltage (DC) 400V
Average Rectified Current 3A
Reverse Recovery Time 75 ns
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 400V
Peak Non-Repetitive Surge Current 125A
Reverse Voltage 400V
Recovery Time 75 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
