MURS140HE3/52T
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE RECT 1A 400V 50NS DO-214AA
PDF
/
Inventory: 1532
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 5μA
Non-rep Pk Forward Current-Max 35A
Reverse Recovery Time 75 ns
Number of Phases 1
Average Rectified Current 1A
Max Reverse Voltage (DC) 400V
Voltage - DC Reverse (Vr) (Max) 400V
Application EFFICIENCY
Output Current-Max 2A
Operating Temperature - Junction -65°C~175°C
Voltage - Forward (Vf) (Max) @ If 1.25V @ 1A
Current - Reverse Leakage @ Vr 5μA @ 400V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-C2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q101
Published 2015
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
