MBRB16H60-E3/81
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 16A TO263AB
PDF
/
Inventory: 9936
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Peak Non-Repetitive Surge Current 150A
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Reverse Current 100μA
Number of Phases 1
Average Rectified Current 16A
Max Reverse Voltage (DC) 60V
Application EFFICIENCY
Max Surge Current 150A
Operating Temperature - Junction -65°C~175°C
Max Reverse Leakage Current 100μA
Forward Current 16A
Voltage - Forward (Vf) (Max) @ If 730mV @ 16A
Current - Reverse Leakage @ Vr 100μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number MBRB16H60
Terminal Form GULL WING
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, LOW POWER LOSS
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
