GPP60D-E3/54
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 200V 6A 2-Pin Case P600 T/R
PDF
/
Inventory: 8156
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Recovery Time 5.5 μs
Reverse Voltage 200V
Peak Non-Repetitive Surge Current 500A
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 5μA
Reverse Recovery Time 5.5 μs
Number of Phases 1
Average Rectified Current 6A
Max Reverse Voltage (DC) 200V
Application GENERAL PURPOSE
Output Current-Max 6A
Max Surge Current 500A
Operating Temperature - Junction -55°C~175°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.1V @ 6A
Current - Reverse Leakage @ Vr 5μA @ 200V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
JESD-30 Code O-PALF-W2
Pin Count 2
Base Part Number GPP60D
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2017
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case P600, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
