GP10Q-E3/54
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1.2KV 1A DO204AL
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.25256
≥100 USD $0.175296
≥500 USD $0.136858
≥1000 USD $0.118694
Inventory: 1288
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Recovery Time 3 μs
Reverse Voltage 1.2kV
Peak Non-Repetitive Surge Current 25A
Capacitance @ Vr, F 7pF @ 4V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Reverse Current 5μA
Reverse Recovery Time 3 μs
Average Rectified Current 1A
Max Reverse Voltage (DC) 1.2kV
Forward Voltage 1.2V
Voltage - DC Reverse (Vr) (Max) 1200V
Output Current-Max 1A
Max Surge Current 25A
Operating Temperature - Junction -65°C~150°C
Forward Current 1A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.2V @ 1A
Current - Reverse Leakage @ Vr 5μA @ 1200V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number GP10Q
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SUPERECTIFIER?
Published 2016
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AL, DO-41, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
