GP10M-4007-M3/54
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 1A DO204AL
PDF
/
Inventory: 8380
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Capacitance @ Vr, F 7pF @ 4V 1MHz
Reverse Recovery Time 3 μs
Average Rectified Current 1A
Max Reverse Voltage (DC) 1kV
Current - Average Rectified (Io) 1A
Voltage - DC Reverse (Vr) (Max) 1000V
Operating Temperature - Junction -65°C~175°C
Voltage - Forward (Vf) (Max) @ If 1.2V @ 1A
Current - Reverse Leakage @ Vr 5μA @ 1000V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Automotive, AEC-Q101, Superectifier?
Packaging Tape & Reel (TR)
Physical
Supplier Device Package DO-204AL (DO-41)
Package / Case DO-204AL, DO-41, Axial
Mounting Type Through Hole
Mount Through Hole
