FESE8HT-E3/45
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 500V 8A TO220AC
PDF
/
Inventory: 5282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 10μA
Non-rep Pk Forward Current-Max 125A
Capacitance @ Vr, F 50pF @ 4V 1MHz
JEDEC-95 Code TO-220AC
Reverse Recovery Time 50 ns
Number of Phases 1
Average Rectified Current 8A
Max Reverse Voltage (DC) 500V
Voltage - DC Reverse (Vr) (Max) 500V
Application EFFICIENCY
Output Current-Max 8A
Operating Temperature - Junction -55°C~150°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.5V @ 8A
Current - Reverse Leakage @ Vr 10μA @ 500V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
JESD-30 Code R-PSFM-T2
Reach Compliance Code unknown
Terminal Position SINGLE
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2017
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case TO-220-2
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
