EGP50GHE3/54
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 400V 5A GP20
PDF
/
Inventory: 9151
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Recovery Time 50 ns
Reverse Voltage 400V
Peak Non-Repetitive Surge Current 150A
Capacitance @ Vr, F 75pF @ 4V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 400V
Peak Reverse Current 5μA
Reverse Recovery Time 50 ns
Number of Phases 1
Average Rectified Current 5A
Max Reverse Voltage (DC) 400V
Application EFFICIENCY
Output Current-Max 5A
Max Surge Current 150A
Operating Temperature - Junction -65°C~150°C
Forward Current 5A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.25V @ 5A
Current - Reverse Leakage @ Vr 5μA @ 400V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
JESD-30 Code O-PALF-W2
Pin Count 2
Base Part Number EGP50G
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series SUPERECTIFIER?
Published 2012
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 20
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
