EGP10DHM3/73
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 200V 1A DO204AL
PDF
/
Inventory: 9991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Capacitance @ Vr, F 22pF @ 4V 1MHz
Reverse Recovery Time 50 ns
Average Rectified Current 1A
Max Reverse Voltage (DC) 200V
Voltage - DC Reverse (Vr) (Max) 200V
Output Current-Max 1A
Operating Temperature - Junction -65°C~150°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 950mV @ 1A
Current - Reverse Leakage @ Vr 5μA @ 200V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
JESD-30 Code O-PALF-W2
Reach Compliance Code unknown
Terminal Form WIRE
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Automotive, AEC-Q101
Published 2012
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Package / Case DO-204AL, DO-41, Axial
Mounting Type Through Hole
Mount Through Hole
