BYT53F-TAP
RoHS
RoHS compliant
RoHS compliantPackage SOD-57, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 300V 1.9A 2-Pin SOD-57 Ammo
PDF
/
Inventory: 4936
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Silver, Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case SOD-57, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Published 2012
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Silver (Sn96.5Ag3.5)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form WIRE
Peak Reflow Temperature (Cel) 260
Current Rating 1.9A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Avalanche
Current - Reverse Leakage @ Vr 5μA @ 300V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Case Connection ISOLATED
Forward Current 1.9A
Operating Temperature - Junction -55°C~175°C
Max Surge Current 50A
Application ULTRA FAST SOFT RECOVERY
Forward Voltage 1.1V
Max Reverse Voltage (DC) 300V
Average Rectified Current 1.9A
Number of Phases 1
Reverse Recovery Time 50 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 300V
Peak Non-Repetitive Surge Current 50A
Reverse Voltage 300V
Recovery Time 50 ns
Compliance
RoHS Status ROHS3 Compliant
