30WQ10FN
RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 3.5A DPAK
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 1111
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Supplier Device Package D-PAK (TO-252AA)
Technical
Packaging Tube
Published 2007
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Capacitance 92pF
Voltage - Rated DC 100V
Current Rating 3.5A
Base Part Number 30WQ10
Polarity Standard
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 1mA @ 100V
Output Current 3.5A
Voltage - Forward (Vf) (Max) @ If 810mV @ 3A
Max Reverse Leakage Current 1mA
Operating Temperature - Junction -40°C~150°C
Max Surge Current 440A
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 3.5A
Forward Voltage 810mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 3.5A
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
