DSF01S30SC(TPL3)
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Schottky Diodes & Rectifiers SM Sig Schotky Diode 30V 0.1A Single
PDF
/
Inventory: 1315
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, No Lead
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2009
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Base Part Number DSF01S30
Case Code (Metric) 0603
Case Code (Imperial) 0201
Element Configuration Single
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 50μA @ 30V
Voltage - Forward (Vf) (Max) @ If 500mV @ 100mA
Forward Current 100mA
Max Reverse Leakage Current 50μA
Operating Temperature - Junction 125°C Max
Max Surge Current 2A
Max Reverse Voltage (DC) 30V
Average Rectified Current 100mA
Peak Reverse Current 50μA
Max Repetitive Reverse Voltage (Vrrm) 30V
Capacitance @ Vr, F 9.3pF @ 0V 1MHz
Peak Non-Repetitive Surge Current 2A
Dimensions
Height 300μm
Length 620μm
Width 320μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
