STTH802SFY
RoHS
/
Package TO-277, 3-PowerDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Ultra Fast Recovery 200V 8A 3-Pin TO-277A T/R
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
≥10 USD $0.54296
≥100 USD $0.37576
≥500 USD $0.313966
≥1000 USD $0.267212
≥3000 USD $0.237987
Inventory: 1810
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-277, 3-PowerDFN
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, ECOPACK?2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Additional Feature FREE WHEELING DIODE, SNUBBER DIODE
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH802
JESD-30 Code R-PDSO-F3
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 6μA @ 200V
Case Connection CATHODE
Operating Temperature - Junction -40°C~175°C
Application ULTRA FAST RECOVERY
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) 8A
Number of Phases 1
Reverse Recovery Time 35ns
Rep Pk Reverse Voltage-Max 200V
JEDEC-95 Code TO-277A
Non-rep Pk Forward Current-Max 150A
Forward Voltage-Max 1.08V
Reverse Current-Max 6μA
