STTH5L06FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2 Full Pack, Isolated Tab
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 5A TO220FP
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.645216
≥100 USD $0.468336
≥500 USD $0.391336
≥1000 USD $0.333054
≥3000 USD $0.296622
Inventory: 1165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2 Full Pack, Isolated Tab
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 600V
Current Rating 5A
Base Part Number STTH5L06
Pin Count 3
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 600V
Output Current 5A
Voltage - Forward (Vf) (Max) @ If 1.3V @ 5A
Forward Current 5A
Operating Temperature - Junction 175°C Max
Max Surge Current 90A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Forward Voltage 1.3V
Max Reverse Voltage (DC) 600V
Average Rectified Current 5A
Number of Phases 1
Reverse Recovery Time 95 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 90A
Reverse Voltage 600V
Max Forward Surge Current (Ifsm) 90A
Recovery Time 95 ns
Dimensions
Height 9.3mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
