STTH3L06UFY
RoHS
RoHS compliant
RoHS compliantPackage DO-221AA, SMB Flat Leads
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
STMICROELECTRONICS STTH3L06UFY Standard Recovery Diode, Single, 600 V, 3 A, 1.4 V, 70 ns, 30 A
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.6512
≥1 USD $0.6512
≥10 USD $0.56584
≥100 USD $0.3916
≥500 USD $0.327166
≥1000 USD $0.278441
≥3000 USD $0.247993
Inventory: 1936
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Forward Surge Current (Ifsm) 30A
Reverse Current-Max 3μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Reverse Recovery Time 70 ns
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 600V
Forward Voltage 1.4V
Application HIGH VOLTAGE ULTRA FAST RECOVERY POWER
Operating Temperature - Junction -40°C~175°C
Forward Current 3A
Voltage - Forward (Vf) (Max) @ If 1.4V @ 3A
Current - Reverse Leakage @ Vr 3μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Base Part Number STTH3L
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Additional Feature LOW LEAKAGE CURRENT
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, ECOPACK?2
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-221AA, SMB Flat Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 8 Weeks
