STTH3L06U
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 3A SMB
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.4224
≥1 USD $0.4224
≥10 USD $0.33
≥100 USD $0.198264
≥500 USD $0.183533
≥1000 USD $0.124802
Inventory: 8273
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.45mm
Technical
Recovery Time 85 ns
Max Forward Surge Current (Ifsm) 60A
Reverse Voltage 600V
Peak Non-Repetitive Surge Current 60A
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Reverse Current 3μA
Reverse Recovery Time 85 ns
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 600V
Forward Voltage 1.3V
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Max Surge Current 60A
Operating Temperature - Junction 175°C Max
Forward Current 3A
Voltage - Forward (Vf) (Max) @ If 1.3V @ 3A
Output Current 3A
Current - Reverse Leakage @ Vr 3μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number STTH3L
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 3A
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Voltage - Rated DC 600V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
