STTH3L06B-TR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description Rectifiers RECTIFIER
PDF
/
Inventory: 7225
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Diode Element Material SILICON

Technical

Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 600V
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Current Rating 3A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH3L
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 3μA @ 600V
Output Current 3A
Voltage - Forward (Vf) (Max) @ If 1.3V @ 3A
Case Connection CATHODE
Operating Temperature - Junction 175°C Max
Max Surge Current 40A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Forward Voltage 1.3V
Max Reverse Voltage (DC) 600V
Average Rectified Current 3A
Number of Phases 1
Reverse Recovery Time 85 ns
Peak Reverse Current 3μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 40A
Reverse Voltage 600V
Recovery Time 85 ns

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free

Alternative Model

STB16NK65Z-S

STB16NK65Z-S

STMicroelectronics

Recommended For You

AO5401E

AO5401E

Alpha & Omega Semiconductor Inc.
