STTH30ST06GY-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 30A D2PAK
PDF
/
Buying Options
Total Price: USD $2.14
Unit Price: USD $2.139571
≥1 USD $2.139571
≥10 USD $2.018464
≥100 USD $1.904211
≥500 USD $1.796425
≥1000 USD $1.694742
Inventory: 1361
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 50μA
Non-rep Pk Forward Current-Max 160A
Reverse Recovery Time 50 ns
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 600V
Voltage - DC Reverse (Vr) (Max) 600V
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Operating Temperature - Junction -40°C~175°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 3.6V @ 30A
Current - Reverse Leakage @ Vr 50μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
JESD-30 Code R-PSSO-G2
Base Part Number STTH30
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Subcategory Rectifier Diodes
Additional Feature SOFT FACTOR IS 0.3
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Automotive, AEC-Q101, ECOPACK?2
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
