STTH30L06P
RoHS
RoHS compliant
RoHS compliantPackage SOD-93-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 600V 50A 2-Pin(2+Tab) DOP3I Tube
PDF
/
Inventory: 5002
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Reverse Recovery Time 90 ns
Non-rep Pk Forward Current-Max 160A
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 600V
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Operating Temperature - Junction 175°C Max
Voltage - Forward (Vf) (Max) @ If 1.55V @ 30A
Output Current 30A
Current - Reverse Leakage @ Vr 25μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
Qualification Status Not Qualified
Pin Count 2
Base Part Number STTH30
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 30A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Rated DC 600V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case SOD-93-2
Mounting Type Through Hole
Mount Through Hole
