STTH30AC06FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 30A TO220
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.5048
≥1 USD $1.5048
≥10 USD $1.20912
≥100 USD $0.99484
≥500 USD $0.84179
≥1000 USD $0.714243
≥3000 USD $0.678533
Inventory: 1046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tube
Series ECOPACK?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH30
JESD-30 Code R-PSFM-T2
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 20μA @ 600V
Voltage - Forward (Vf) (Max) @ If 1.95V @ 30A
Case Connection ISOLATED
Operating Temperature - Junction 175°C Max
Output Current-Max 30A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 30A
Number of Phases 1
Reverse Recovery Time 60ns
Rep Pk Reverse Voltage-Max 600V
JEDEC-95 Code TO-220AC
Non-rep Pk Forward Current-Max 270A
Reverse Current-Max 20μA
Compliance
RoHS Status ROHS3 Compliant
