STTH3010W
RoHS
RoHS compliant
RoHS compliantPackage DO-247-2 (Straight Leads)
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 30A DO247
PDF
/
Buying Options
Total Price: USD $3.33
Unit Price: USD $3.3264
≥1 USD $3.3264
≥10 USD $2.63912
≥100 USD $2.26197
≥500 USD $2.010642
≥1000 USD $1.721614
≥3000 USD $1.621083
Inventory: 748
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-247-2 (Straight Leads)
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, HIGH RELIABILITY
HTS Code 8541.10.00.80
Capacitance 12pF
Subcategory Rectifier Diodes
Voltage - Rated DC 1kV
Current Rating 30A
Base Part Number STTH30
Pin Count 2
JESD-30 Code R-PSFM-T2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 15μA @ 1000V
Output Current 30A
Voltage - Forward (Vf) (Max) @ If 2V @ 30A
Forward Current 20A
Operating Temperature - Junction 175°C Max
Max Surge Current 180A
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 1000V
Forward Voltage 2V
Max Reverse Voltage (DC) 1kV
Average Rectified Current 30A
Number of Phases 1
Reverse Recovery Time 100 ns
Peak Reverse Current 15μA
Max Repetitive Reverse Voltage (Vrrm) 1kV
Peak Non-Repetitive Surge Current 180A
Reverse Voltage 1kV
Max Forward Surge Current (Ifsm) 180A
Recovery Time 100 ns
Dimensions
Length 15.75mm
Width 5.15mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
