STTH2R02Q
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 200V 2A DO15
PDF
/
Inventory: 9418
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH2R
Pin Count 2
JESD-30 Code O-PALF-W2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 3μA @ 200V
Voltage - Forward (Vf) (Max) @ If 1V @ 2A
Case Connection ISOLATED
Operating Temperature - Junction 175°C Max
Max Surge Current 75A
Output Current-Max 2A
Application ULTRA FAST RECOVERY
Max Reverse Voltage (DC) 200V
Average Rectified Current 2A
Number of Phases 1
Reverse Recovery Time 30 ns
Peak Reverse Current 3μA
Reverse Voltage 200V
Recovery Time 30 ns
Compliance
RoHS Status ROHS3 Compliant
