STTH208U
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 800V 2A SMB
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.4224
≥1 USD $0.4224
≥10 USD $0.36432
≥100 USD $0.253264
≥500 USD $0.197754
≥1000 USD $0.160732
Inventory: 1500
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -50°C
Additional Feature HIGH RELIABILITY, SNUBBER DIODE, FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 800V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Current Rating 2A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH2
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 800V
Output Current 2A
Voltage - Forward (Vf) (Max) @ If 1.65V @ 2A
Forward Current 2A
Operating Temperature - Junction 175°C Max
Max Surge Current 35A
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Forward Voltage 1.65V
Max Reverse Voltage (DC) 800V
Average Rectified Current 2A
Number of Phases 1
Reverse Recovery Time 75 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 800V
Peak Non-Repetitive Surge Current 35A
Reverse Voltage 800V
Max Forward Surge Current (Ifsm) 35A
Recovery Time 75 ns
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
