STTH208RL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 800V 2A DO15
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.144715
≥1 USD $0.144715
≥10 USD $0.136521
≥100 USD $0.128793
≥500 USD $0.121505
≥1000 USD $0.114621
Inventory: 1241
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Recovery Time 75 ns
Reverse Voltage 800V
Peak Reverse Current 5μA
Reverse Recovery Time 75 ns
Number of Phases 1
Average Rectified Current 2A
Max Reverse Voltage (DC) 800V
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Max Surge Current 45A
Operating Temperature - Junction 175°C Max
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.65V @ 2A
Output Current 2A
Current - Reverse Leakage @ Vr 5μA @ 800V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PALF-W2
Pin Count 2
Base Part Number STTH2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 2A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Voltage - Rated DC 800V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY, SNUBBER DIODE, FREE WHEELING DIODE
Min Operating Temperature -50°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
