STTH1R06A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 1A SMA
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.186574
≥1 USD $0.186574
≥10 USD $0.176015
≥100 USD $0.166059
≥500 USD $0.156659
≥1000 USD $0.147785
Inventory: 1394
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Weight 45.359237g
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 600V
Technology SCHOTTKY
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number STTH1
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 1μA @ 600V
Output Current 1A
Voltage - Forward (Vf) (Max) @ If 1.7V @ 1A
Forward Current 1A
Operating Temperature - Junction 175°C Max
Max Surge Current 20A
Forward Voltage 1.7V
Max Reverse Voltage (DC) 600V
Average Rectified Current 1A
Reverse Recovery Time 45 ns
Peak Reverse Current 1μA
Max Repetitive Reverse Voltage (Vrrm) 600V
RMS Current (Irms) 7A
Peak Non-Repetitive Surge Current 20A
Reverse Voltage 600V
Max Forward Surge Current (Ifsm) 20A
Recovery Time 45 ns
Natural Thermal Resistance 30 °C/W
Dimensions
Height 2.03mm
Length 4.6mm
Width 2.95mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
